Med Vest Technology Envoy Plus Central Monitoring System
Unite Your Setup with Med Vest Technology Envoy Plus Central Monitoring System
0 item is in your cart. View cart now
All product and company names are trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement or sponsorship by them.
Increased efficiency, better quality
The Med Vest Technology Envoy Plus brings you a comprehensive central monitoring solution for all Med Vest Technology bedside monitors. It offers seamless remote monitoring management from transportation, hospitalization, intensive care to anesthesia care and beyond, bringing easy access to health care providers with well-organized monitoring technology
The Med Vest Technology Envoy Plus Central Monitoring System is available through Med Vest Technology. Contact your Med Vest Technology representative today for more information.
Features
- Up to 240 hours of trend data and storage review
- 12-lead ECG display
- 12 hour short trend data
- Printing report
- Simultaneous monitoring of up to 64 patients
- Storage of patient’s history data
- Transfer waveforms, alarms, parameters, etc
- Waveform storage and review: Up to 240 hours of waveform data per monitor/device; default 96 hours
- NIBP measurement storage and review: Stores up to 720 NIBP measurements per monitor
- 12-lead analysis results: Stores up to 720 12-lead analysis results per monitor
- C.O. measurements: Stores up to 720 C.O measurements per monitor
- Quick TEMP measurements: Stores up to 720 Quick TEMP measurements per monitor
- PAWP measurements: Stores up to 720 PAWP measurements per monitor
- Alarm events: 720 parameter alarm events per monitor/device
- Alarm types: Physiological alarm; technical alarm
- Alarm mode: Three levels of audio and visual alarms
Storage capacity for each patient
Specifications
Physiological Waveforms
- 2 ECG Waveforms
- 1 RESP waveform
- 1 PLETH waveform
- 8 IBP waveforms
- 1 CO2 waveform
- 4 AG waveforms for CO2, O2, N2O and AA
- 3 RM waveforms
- 1 CO2 (RM) waveforms
- 1 ICG waveform
- 1 BIS waveform
Auxiliary Screen Sub-Window Options
- Single Bed View (default)
- Patient Mgmt
- Wave Review
- Alarm Review
- Trend Review
- NIBP Review
- Parameter/Waveform Setup
- 12-L Review
- C.O. measure review
- Quick TEMP Review
- PAWP Review
- Calculation
Wave Speed
- 6.25 mm/s
- 12.5 mm/s
- 25 mm/s
- 50 mm/s
Med Vest Technology central monitoring station communicates with Med Vest Technology monitors on a bi-directional basis. Up to 64 units of can be connected to MFM-CMS by wireless or wired LAN. A typical system will be 6 to 12 units.
