Maxtec MaxO2 ME Oxygen Monitor
Maxtec MaxO2 ME Oxygen Monitor
0 item is in your cart. View cart now
All product and company names are trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement or sponsorship by them.
Details
Low-maintenance oxygen monitor with adjustable alarms, long battery life, and large LCD screen
The Maxtec MaxO2 ME is an oxygen monitor is a simple, easy-to-use oxygen monitor that fits seamlessly into almost any care environment. With a large, backlit LCD screen, clinicians can easily view and analyze patient levels, even in low light. Intuitive hard keys allow for quick and easy operation.
For more information on the Maxtec MaxO2 ME Oxygen Monitor available from Med Vest Technology, contact an Avante representative today.
Features
- Large LCD screen is backlit for increased clarity, even in low-light environments.
- Long battery life provides up to 5,000 hours of use on four AA batteries.
- Easy-to-use smart alarms can be set within 3% of the current reading.
- Low alarm capabilities of 15% to 99%.
- DC power port for use with an optional remote power supply.
- External proprietary O2 sensor with long-life smart sensor.
- Built-in kickstand and dovetail mounts easily to ventilator, I.V. pole, or wall.
Specifications
General
- Measurement range: 0% to 100%
- Display resolution: 0.10%
- Response time: 90% of final value < 15 seconds at 23 °C
- Warm-up time: none required
- Calibration reminder: one week timer; restarted every calibration
- Sensor type: Maxtec MAX-550 Series galvanic fuel cell
- Sensor connection: M16x1 thread
- Sensor operating life: > 1,500,000 oxygen percent hours
Alarms
- High alarm: 18% to 99%
- Low alarm range: 15 to 99%
- Alarm accuracy: exact to displayed O2 values
- Alarm system: high/low alarm system, flashing yellow LEDs, nominal 975 Hz audio buzzer
- Linearity: +/- 1% of full-scale at constant temperature and pressure
- Accuracy: +/- 1% of full-scale at constant temperature, relative humidity, and pressure
Environmental
- Min/max storage temperature: 5°F to 122°F
- Operating temperature: 59°F to 104°F
Power
- Power requirements: 4 AA alkaline batteries
- Optional remote power supply: optional 7.5 VDC power adapter (does not function as a charger; only extends battery life)
- Battery life: 5,000 hours (continuous monitoring; no alarms, no backlighting)
- Low battery indicator: on-screen icon
Physical
- Dimensions: 3.6 x 5.8 x 1.2 in
- Weight: < 1.5 lbs
- Cable length: 10 ft when fully extended
