Transmotion TMM4 PLUS-154 Mammography/Biopsy Stretcher-Chair

Transmotion TMM4 PLUS-154 Mammography/Biopsy Stretcher-Chair

Web ID: 36087

0 item is in your cart. View cart now

Need help choosing?

Ask an Equipment Expert

(781) 302-6019

Listing Terms & Conditions

All product and company names are trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement or sponsorship by them.

Details

The TMM4-154 Mammography / Biopsy Stretcher-Chair is designed

to accommodate seated mammography and breast biopsy

procedures ordered for patients at hospitals and imaging centers. In

the seated position, the TMM4 requires half the space of a traditional

stretcher and is easy to navigate through hallways, rooms, elevators,

and other close quarters. Plus, its' large radiolucent back enables in-

chair imaging procedures.

  • Safely accommodate patients who are unable to stand or who have a vasovagal syncope risk.
  • Eliminate the need to transfer patients to a radiologic table and reduce the risk of injury to patients and staff
  • Easily position patients at the push of a button.

Specifications

Seat Height - Low: 22.8 inches (57.9 cm)

Seat Height - High: 30.6 inches (77.7 cm)

Patient Seat Width: 24 inches (61 cm)

Overall Width (Rails Down): 28 inches (71 cm)

Overall Width (Rails Up): 34 inches (86.4 cm)

Patient Surface Length: 70 inches (179 cm)

Overall Chair Height - Low: 52 inches (133 cm)

Overall Chair Height - High: 62 inches (157 cm)

Backrest Articulation: 0Ā° - 75Ā°

Trendelenburg: 5Ā°

Reverse Trendelenburg: 0Ā°

Side Rails - Height: 13.5 inches (34.3 cm)

Side Rails - Length: 27.6 inches (70.1 cm)

Chair Weight - 200 - 205 lbs (90 - 113 kg)

Max Patient Weight: 500 lbs (227 kg)

Charging System - Input Volts: 100 - 240 VAC

Charging System - Current: 1.0A (Max)

Charging System - Frequency: 50/60 HZ

Charging System Max Power: 36.0W

Cushion Flammability Rating: TB-117

-->
