GE OEC 6800 Mini C-arm System

Brand: GE

Type: C-Arm - Fluoroscopy Machines

Web ID: 12297

Condition: Brand New

Product Number: 6M6800

0 item is in your cart. View cart now

Need help choosing?

Ask an Equipment Expert

(781) 302-6019

Listing Terms & Conditions

All product and company names are trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement or sponsorship by them.

Details

The GE OEC 6800 is a compact, mini C-arm with touchscreen operation and 1k x 1k 16-bit image processing. Features an on-board CCD camera and advanced image processing software. For more information on the GE OEC 6800 Mini C-arm, available New through Med Vest Technology, contact an Med Vest Technology representative today.

Features

Mini C-arm used for scanning hands, feet, ankles, wrists, knees and shoulders.
First mini C-arm to feature touchscreen operation and 1k x 1k 16-bit image processing.
Small footprint measures 27 inches by 27 inches.
Dual 16-inch high resolution monitors.
Real-time motion artifact and noise reduction system.
Automatic and manual digital brightness and contrast control.
Last Image Hold helps to reduce the patient’s radiation exposure.
Noise filter with on-screen indicator.
Onboard CCD camera for digital imaging.
Bilateral x-ray tube mounted controls.
Save and auto-save, swap and auto-swap features.

3.5 floppy or CD drive, thermal printer.
Multi-purpose image directory.
Dual mode, 6-inch image intensifier.
Available in a clinical or hospital platform.
Power: 40-80 kVp.
Hospital platform includes: 400-image capacity, real-time variable edge enhancement, zoom and roam function.
Optional — Laser aimer, onboard DICOM, interactive touchscreen menu.
Optional — Surgical package software.
Optional — Flat panel monitor upgrade with side to side, vertical movement.

Specifications

C-arm Dimensions

65 in (H) x 28 in (W) x 28 in (D)
Vertical movement: 27 in
Free space: 13.8 in
Reverse position: Yes
Rotation: 115°
Depth: 17.7 in
Pivot rotation: 220°
Panning movement: 230°
Monitor size: 16 inch Dual Monitors

Image Processing and Storage

Max. number of images: 400 CP, 800 HP
Frame integration: Yes
Image matrix size: 1000 x 1000 x 16
Last Image Hold: Yes

Power Consumption

100, 240 VAC; 6,4A
Generator: High-frequency
Abs control: kVp, A
Kv range: 40
Ma range: 0.02-0.16
Snapshot function: Yes

General

Image Intensifier Diameter: 15, 10 cm (6, 4 in)
Maximum output at 120VAC: 0.16 mA @ 80 kVp
Heat capacity: 7000 HU
Fluoroscopic Mode: 0.045
Cooling: 3000 HU/min
